4.8 discovery sound on but video not work

**jenseneverest** · Nov 13th 2021

Quote from samur

same probleme on : Discovery Hungary (0.8°W ) sound ok but video no for almost 3 days ;
is it a new encryption ...?
tested with OSCam .
;

Its not really a cam issue, it is missing the video pid from the stream, some non enigma2 boxes have no issues

so you could edit the pid in your lamedb file to fix the video pid

BUT then the key will need to be added to oscam like a constant CW......

the problem with that is it will only decode one CW.

So it is a 2 fold problem. For now all the channels can still be viewed between both 4.8e and 0.8w

But as said it is the way enigma2 handles channels with pmt

Code

oscam.dvdapi

P: 0E00

# A: ::service ID:[PMT PID] :[provider ID][:][ECM PID]
# set a dummy ECM request with CAID FFFF for services with a constant CW shown as unencrypted service (for STBs with PMT PID support only)
#
# A: ::service ID:[video PID] :[provider ID][:][ECM PID]
# set a dummy ECM request with CAID FFFF for services with a constant CW shown as unencrypted service (for STBs without PMT PID support only)
#
# X: [CAID]:[provider ID]:[service ID]:[ECM PID]
# add decoding on an extra demux index on the same CA device (Multi ECM) (not support on all STBs)
#
# non pmtpid
# A: ::SID:VPID:CAID:ECM
# A: ::000a:008a 2600::1fff #ERT 1 39E/12224H
# A: ::0014:008b 2600::1fff #ERT 2 39E/12224H#
# A: ::0028:008d 2600::1fff #ERT 1 HD 39E/12224H
# A: ::0001:0080 2600::1fff #ERT 1 HD 39E/12242H
# A: ::0002:0081 2600::1fff #ERT 1 HD 39E/12242H
# A: ::0007:0086 2600::1fff #ERT1. 39E/12242H
# pmtpid
# A: ::SID:PMT:CAID:ECM
# A: ::000a:0104 2600:1fff #ERT 1 39E/12224H
# A: ::0014:0100 2600::1fff #ERT 2 39E/12224H
# A: ::0028:0102 2600:000000:1fff #ERT 1 HD 39E/12224H
# A: ::0001:0100::: 2600:000000:1fff #ERT 2 HD 39E/12242H
# A: ::0002:0101::: 2600:000000:1fff #ERT 3 HD 39E/12242H
# A: ::0007:010e::: 2600:000000:1fff #ERT1. 39E/12242H

A: ::06a4:06a4 0e00::177d
A: ::04b0:04b0 0e00::1775
A: ::0834:0834 0e00::177f
A: ::0708:0708 0e00::177e
A: ::0c1c:0c1c 0e00::1771

#X: 0e00:000000:06a4:177d
#X: 0e00:000000:04b0:1775
#X: 0e00:000000:0834:177f
#X: 0e00:000000:0708:177e
#X: 0e00:000000:0c1c:1771

Display More

lamedb

Code

eDVB services /4/
transponders
0031b048:0001:005e
    s 12360000:27500000:1:4:49:2:0:1:2:0:2
/
end
services
0708:0031b048:0001:005e:1:0:0
Science Poland HD
p:,c:000708,c:01070b,c:020713,c:030708,c:050001,C:0e00,f:404
0c1c:0031b048:0001:005e:1:0:0
TLC Poland HD
p:,c:000c1c,c:010c1f,c:020c27,c:030c1c,c:050001,C:0e00,f:404
0320:0031b048:0001:005e:1:0:0
TLC Balkans
p:,c:000320,c:010324,c:030320,c:050001,C:0e00
012c:0031b048:0001:005e:1:0:0
HGTV Pan Regional HD
p:,c:00012c,c:01012f,c:03012c,c:050001,C:0500
0834:0031b048:0001:005e:1:0:0
ID Poland
p:,c:000834,c:010835,c:030834,c:050001,C:0e00,f:404
0b54:0031b048:0001:005e:1:0:0
TLC Pan Regional
p:,c:000b54,c:010b57,c:030b54,c:050001,C:0e00
0258:0031b048:0001:005e:1:0:0
Turbo Xtra Poland
p:,c:000258,c:010259,c:030258,c:050001,C:0e00
0064:0031b048:0001:005e:1:0:0
Travel EMEA HD
p:,c:000064,c:010067,c:030064,c:050001,C:0500
0898:0031b048:0001:005e:1:0:0
Discovery Sweden
p:,c:000898,c:010899,c:030898,c:050001,C:0e00
06a4:0031b048:0001:005e:1:0:0
Animal Planet Poland HD
p:,c:0006a4,c:0106a7,c:0206af,c:0306a4,c:050001,C:0e00,f:4
04b0:0031b048:0001:005e:1:0:0
Discovery Poland
p:,c:0004b0,c:0104b1,c:0304b0,c:050001,C:0e00,f:4
03e8:0031b048:0001:005e:1:0:0
TLC Hungary
p:,c:0003e8,c:0103eb,c:0303e8,c:050001,C:0e00
01f4:0031b048:0001:005e:1:0:0
TLC Balkans HD
p:,c:0001f4,c:0101f9,c:0301f4,c:050001,C:0500
125c:0031b048:0001:005e:25:0:0
ESP2 PAN HD
p:Eurosport,c:00125c,c:011266,c:03125c,c:050001,c:1612b6,f:4
end
Have a lot of bugs!

Display More

Credit EnoSat for the above, on another well know feed hunter forum

**car123** · Nov 14th 2021

yes it is

**jenseneverest** · Nov 14th 2021

Quote from car123

yes it is

What is ? The sun is out ? ITs raining ?? What is ??

hutnteroffeed · Nov 14th 2021

Quote from jenseneverest
Quote from samur

same probleme on : Discovery Hungary (0.8°W ) sound ok but video no for almost 3 days ;
is it a new encryption ...?
tested with OSCam .
;

Its not really a cam issue, it is missing the video pid from the stream, some non enigma2 boxes have no issues
so you could edit the pid in your lamedb file to fix the video pid
BUT then the key will need to be added to oscam like a constant CW......

the problem with that is it will only decode one CW.
So it is a 2 fold problem. For now all the channels can still be viewed between both 4.8e and 0.8w
But as said it is the way enigma2 handles channels with pmt
Code
oscam.dvdapi

P: 0E00

# A: ::service ID:[PMT PID] :[provider ID][:][ECM PID]
# set a dummy ECM request with CAID FFFF for services with a constant CW shown as unencrypted service (for STBs with PMT PID support only)
lamedb
Code
eDVB services /4/
transponders
0031b048:0001:005e
    s 12360000:27500000:1:4:49:2:0:1:2:0:2
/
end
services
0708:0031b048:0001:005e:1:0:0
Science Poland HD
p:,c:000708,c:01070b,c:020713,c:030708,c:050001,C:0e00,f:404
Credit EnoSat for the above, on another well know feed hunter forum
Display More

does it work?

lider · Nov 27th 2021

Quote from moorman

read post 5

now work s oscam patch and pid settings.

**jenseneverest** · Nov 27th 2021

here is the fix, please read all of the text files, there is the oscam emu arm version attached

As yet untested by me

**georgeflu** · Nov 27th 2021

Quote from jenseneverest

As yet untested by me

just tested by me... and it works.

just little more slow decoding from the past (but better than nothing :) )

and you have just the only one audio pid that you selected in settings/lamedb fix (but same as above)

lider · Nov 27th 2021

vpid_mapping.patch

this file copied where is?

usr/lib

usr/bin

etc/tuxbox/config ?

**jenseneverest** · Nov 27th 2021

Quote from lider

vpid_mapping.patch

this file copied where is?

usr/lib

usr/bin

etc/tuxbox/config ?

Display More

The patch is to compile oscam with, not required unless you want to patch your own oscam

lider · Nov 27th 2021

ok i am tried

Code

When I throw the lib.so files, the device does not open, it looks like the image will be opened, but it does not open. I restored from a backup image.

Code


**georgeflu** · Nov 27th 2021

try once without lib files...

start emu

if it does not start, than start it from telnet to give us the problem.

if it will ask for the lib files, than just create a symlink (for example libcrypto.so.0.9.8 to libcrypto.so.1.1 )

lider · Nov 27th 2021

Demuxer 0 trying to descramble PID 0 CAID 0E00 PROVID 000000 ECMPID 1FFF ANY CHID PMTPID 0000 VPID 05DC

cengizkartal · Nov 27th 2021

PC Windows 11

Code

2021/11/27 21:22:53 68655FE3 c   (dvbapi) Error in oscam.dvbapi: ret=-1 | d: 0000 000000  0000 10000
2021/11/27 21:22:53 68655FE3 c   (dvbapi) Error in oscam.dvbapi: ret=0 | p: 0000 000000  0000 10000
2021/11/27 21:22:53 68655FE3 c   (dvbapi) Error in oscam.dvbapi: ret=-1 | s: 0000 000000  0000 10000
2021/11/27 21:22:53 68655FE3 c   (dvbapi) Error in oscam.dvbapi: ret=0 | p: 0000 000000  0000 10000
2021/11/27 21:22:53 68655FE3 c   (dvbapi) dvbapi channelcache loaded from /etc/tuxbox/config/oscam.ccache
2021/11/27 21:22:53 68655FE3 c   (dvbapi) Using TCP listen socket, API forced to DVBAPIv3 (0), userconfig boxtype: 12
2021/11/27 21:22:59 45D2E545 r   (reader) SoftCam.Keys [emu] card detected
2021/11/27 21:22:59 68655FE3 c   (dvbapi) Client connected: 'mdvbapi v0.19.1' (protocol version = 2)

**georgeflu** · Nov 27th 2021

this is oscam.log and not from telnet...

but, if you have replaced the oscam.bin file, than it looks that it works...

**jenseneverest** · Nov 27th 2021

Quote from cengizkartal

PC Windows 11

Code

2021/11/27 21:22:53 68655FE3 c   (dvbapi) Error in oscam.dvbapi: ret=-1 | d: 0000 000000  0000 10000
2021/11/27 21:22:53 68655FE3 c   (dvbapi) Error in oscam.dvbapi: ret=0 | p: 0000 000000  0000 10000
2021/11/27 21:22:53 68655FE3 c   (dvbapi) Error in oscam.dvbapi: ret=-1 | s: 0000 000000  0000 10000
2021/11/27 21:22:53 68655FE3 c   (dvbapi) Error in oscam.dvbapi: ret=0 | p: 0000 000000  0000 10000
2021/11/27 21:22:53 68655FE3 c   (dvbapi) dvbapi channelcache loaded from /etc/tuxbox/config/oscam.ccache
2021/11/27 21:22:53 68655FE3 c   (dvbapi) Using TCP listen socket, API forced to DVBAPIv3 (0), userconfig boxtype: 12
2021/11/27 21:22:59 45D2E545 r   (reader) SoftCam.Keys [emu] card detected
2021/11/27 21:22:59 68655FE3 c   (dvbapi) Client connected: 'mdvbapi v0.19.1' (protocol version = 2)

Dose your windows PC run the arm version of oscam like a VU solo4k or what oscam are you using ?

cengizkartal · Nov 27th 2021

I could not capture the image in Oscam somehow

cengizkartal · Nov 27th 2021

Code

021/11/27 21:22:53 00000000 s >> OSCam << cardserver log switched, version 1.20_svn, build r11703-798 (x86_64-pc-cygwin-libusb-pcsc)
2021/11/27 21:22:53 00000000 s (ana) Sistem adı = CYGWIN_NT-10.0-22000
2021/11/27 21:22:53 00000000 s (ana) Ana bilgisayar adı = Tuba
2021/11/27 21:22:53 00000000 sn (ana) Sürüm = 3.3.1-341.x86_64
2021/11/27 21:22:53 00000000 sn (ana) Sürüm = 2021-10-28 20:52 UTC
2021/11/27 21:22:53 00000000 s (ana) Makine = x86_64
2021/11/27 21:22:53 00000000 s (ana) /cygdrive/c/Users/Sibel/AppData/Local/Temp/_oscam/oscam.pid pid 1577 ile pidfile oluşturma
2021/11/27 21:22:53 00000000 s (config) hizmetler yeniden yüklendi: 0 hizmet serbest bırakıldı, 1 hizmet yüklendi, reddedildi 0
2021/11/27 21:22:53 00000000 s (config) CCcam.cfg satırları okuyun: C:7 N:0 L:0 R:0
2021/11/27 21:22:53 00000000 s (emu) OSCam-Emu sürüm 798
2021/11/27 21:22:53 00000000 s (config) userdb yeniden yüklendi: 1 hesap yüklendi, 0'ın süresi doldu, 0 devre dışı bırakıldı
2021/11/27 21:22:53 00000000 s (ana) sinyal işleme başlatıldı
2021/11/27 21:22:53 00000000 s (yapılandırma) 4 sağlayıcı yüklendi
2021/11/27 21:22:53 00000000 s (yapılandırma) 33 hizmet kimliği 0 ms'de yüklendi
2021/11/27 21:22:53 00000000 s (okuyucu) SoftCam.Keys [emu] aygıt /var/keys/SoftCam.keys için iş parçacığı oluşturma
2021/11/27 21:22:53 00000000 s (okuyucu) egygold.in_51001_bigbow40271 [cccam] egygold.in cihazı için iş parçacığı oluşturma
2021/11/27 21:22:53 00000000 s (okuyucu) egygold.in_51002_bigbow40271 [cccam] egygold.in cihazı için iş parçacığı oluşturma
2021/11/27 21:22:53 5851F42D h (webif) webif: sıkıştırılmış 180261 bayt tekrar 475712 bayta dönüştürülür
2021/11/27 21:22:53 45D2E545 r (emu) Akış anahtarı geciktirici başlatıldı
2021/11/27 21:22:53 00000000 s (okuyucu) egygold.in_51003_bigbow40271 [cccam] egygold.in cihazı için iş parçacığı oluşturma
2021/11/27 21:22:53 45D2E545 r (emu) Akış geçiş sunucusu başlatıldı
2021/11/27 21:22:53 00000000 (emu) BİLGİ: FFDecsa paralel mod = 128
2021/11/27 21:22:53 45D2E545 r (okuyucu) SoftCam.Keys [emu] Okuyucu başlatıldı (device=/var/keys/SoftCam.keys, algılama=cd, mhz=357, cardmhz=357)

Display More

lider · Nov 27th 2021

montilla · Nov 27th 2021

E2 için ne yapmamız gerekli

yura21 · Nov 27th 2021

Quote from jenseneverest

here is the fix, please read all of the text files, there is the oscam emu arm version attached

Can someone compile for mipsel (openpli)?
