PiP (Picture in Picture) in PurE2

Since I was asked how PiP (Picture in Pictire) actually works in Zgemma STBs with PurE2, here is a guide.



PiP (Picture in Picture) in PurE2


For H7: MENU > STANDBY/RESTART > MULTIBOOT > ^ or V (up or down) buttons around the OK button, to choose the image variant that has PiP enabled (in fact, in H7 one hasn't got only 4 but actually 8 images: 4 main ones and each image has a PiP version, too). Restart and then...


H7 and H9/H9.2.X series: choose a channel > blue button > activate PiP


Then, blue button > green button, to set it up the way you want it to appear... (read the messages and keep pressing 0 'til you are happy > OK).


Blue > red button to change the window in which you can zap/change/choose different channels > V or ^ buttons to get the list of channels > green button > choose, for instance Terrestrial > choose a channel > OK...


Then blue button > yellow button to swap the places, i.e. which window is active (i.e. which audio you are listening to) > OK...


Play a bit, you can't fuck it up...


Blue > blue to exit PiP...


Njoy!

Like 4

Replies 3

  • What is the path to the blue button to activate PiP? I hotkey that button for my Catchup plugin so would like to make the PiP path a long press.

  • H7 and H9/H9.2.X series: choose a channel > blue button > blue button = activate PiP.


    If you want more, go to System > Keyboard/RC > Extra Button Setup > press a button to assign a function to > InfoBar > Show PiP or whatever you want, from the offering in the list of options...

    Like 1

  • Thanks gorski, that’s the info I was looking for!

    Like 1
