You need a running webserver to be able to use munin.
Munin is a network/system monitoring application that presents output in graphs through a web interface. Its emphasis is on simple plug and play capabilities. A large number of monitoring plugins are available. Using Munin you can easily monitor the performance of your computers, networks, SANs, and applications as well. It uses the RRDtool (written by Tobi Oetiker) and is written in Perl. It stores the data in RRD files, and (if needed) updates the graphs. One of the main goals has been ease of creating new plugins (graphs).
Munin is available as a package in most distros. In Ubuntu for example, to install it, just type: sudo apt-get install munin
With the plugins below, you can very easily monitor vairous CCcam parameters along the many others inside your Munin installation on your Linux system.
If you use Ubuntu, go to /usr/share/munin/plugins/ (other distros may have some other location for this) and create there a file called
cccam_cards
This gives a view of how many cards you get in different hops
#!/bin/sh
case $1 in
config)
cat <<'EOM'
graph_title CCcam available cards
graph_vlabel cards
graph_category CCcam
hop1.label Cards in hop1
hop2.label Cards in hop2
hop3.label Cards in hop3
hop4.label Cards in hop4
hop5.label Cards in hop5
EOM
exit 0;;
esac
echo -n "hop1.value "
echo shares | nc localhost 16000 | grep "|1 " | wc -l
echo -n "hop2.value "
echo shares | nc localhost 16000 | grep "|2 " | wc -l
echo -n "hop3.value "
echo shares | nc localhost 16000 | grep "|3 " | wc -l
echo -n "hop4.value "
echo shares | nc localhost 16000 | grep "|4 " | wc -l
echo -n "hop5.value "
echo shares | nc localhost 16000 | grep "|5 " | wc -l
Display More
cccam_ecm
This gives a view of how many ECM goes trough you box, and how many your local card have handled. (Does not work correct if you have more than one card.
#!/bin/sh
case $1 in
config)
cat <<'EOM'
graph_title CCcam ECM
#graph_vlabel cccam
graph_category CCcam
ecms.label Total handled client ecms
ecmsl.value Local card hadled client ecms
EOM
exit 0;;
esac
echo -n "ecms.value "
echo info | nc localhost 16000 | grep ecm | awk '{print $5}'
echo -n "ecmsl.value "
echo entitlements | nc localhost 16000 | grep handled | awk '{print $2}' | awk 'BEGIN { FS = "(" } ; { print $1 }'
Display More
cccam_peak
Lists the largest peak number of your server
#!/bin/sh
case $1 in
config)
cat <<'EOM'
graph_title CCcam Peak
#graph_vlabel cccam
graph_category CCcam
peak.label Peak load
EOM
exit 0;;
esac
echo -n "peak.value "
echo info | nc localhost 16000 | grep Peak | awk '{print $8}'
Display More
cccam_server_clients
Lists number of connected server and clients. (it should count number instead of using the value form the server page, this also lists users that has gone offline.
#!/bin/sh
case $1 in
config)
cat <<'EOM'
graph_title CCcam Servers and Clients
#graph_vlabel CCcam
graph_category CCcam
clients.label Connected clients
aclient.label Active clients
servers.label Server connections
online.label Online CCcam Servers
EOM
exit 0;;
esac
echo -n "clients.value "
echo info | nc localhost 16000 | grep Connected | awk '{print $3}'
echo -n "aclient.value "
echo info | nc localhost 16000 | grep 'Active clients' | awk '{print $3}'
echo -n "servers.value "
echo servers | nc localhost 16000 | grep 'Server connections' | awk '{print $3}'
echo -n "online.value "
echo servers | nc localhost 16000 | cut -d'|' -f3 | cut -c3-3 | grep "d" | wc -l
Display More
cccam_share
Liste the numbers of shares(cards) your server sees.
#!/bin/sh
case $1 in
config)
cat <<'EOM'
graph_title CCcam Shares
#graph_vlabel cccam
graph_category CCcam
shares.label Available shares
EOM
exit 0;;
esac
echo -n "shares.value "
echo shares | nc localhost 16000 | grep Available | awk '{print $3}'
Display More
cccam_user
Shows how many cards you get from different users. You can add many users. (replace user1.no-ip.com with users correct DNS or IP)
#!/bin/sh
case $1 in
config)
cat <<'EOM'
graph_title CCcam User Cards
#graph_vlabel cccam
graph_category CCcam
user1.label name user1
user2.label name user2
EOM
exit 0;;
esac
echo -n "user1.value "
echo servers | nc localhost 16000 | grep user1.no-ip.com | awk '{print $5}'
echo -n "user2.value "
echo servers | nc localhost 16000 | grep user1.no-ip.com | awk '{print $5}'
Display More
cccam_version_server
Lists how many server you have of different version. You can easy see if some of your peers upgrade to new version.
#!/bin/sh
case $1 in
config)
cat <<'EOM'
graph_title Online CCcam Servers by version
#graph_vlabel CCcam
graph_category CCcam
S2011.label 2.0.11
S210.label 2.1.0
S211.label 2.1.1
S212.label 2.1.2
S213.label 2.1.3
S214.label 2.1.4
S220.label 2.2.0
S221.label 2.2.1
EOM
exit 0;;
esac
echo -n "S2011.value "
echo servers | nc localhost 16000 | grep "|2.0.11 " | wc -l
echo -n "S210.value "
echo servers | nc localhost 16000 | grep "|2.1.0 " | wc -l
echo -n "S211.value "
echo servers | nc localhost 16000 | grep "|2.1.2 " | wc -l
echo -n "S212.value "
echo servers | nc localhost 16000 | grep "|2.1.2 " | wc -l
echo -n "S213.value "
echo servers | nc localhost 16000 | grep "|2.1.3 " | wc -l
echo -n "S214.value "
echo servers | nc localhost 16000 | grep "|2.1.4 " | wc -l
echo -n "S220.value "
echo servers | nc localhost 16000 | grep "|2.2.0 " | wc -l
echo -n "S221.value "
echo servers | nc localhost 16000 | grep "|2.2.1 " | wc -l
Display More
Make these files executable (change permissions with chmod to 755).
eks
chmod 755 /usr/share/munin/plugins/cccam_user
Create symlinks for each file to folder /etc/munin/plugins.
eks
ln -s /usr/share/munin/plugins/cccam_user /etc/munin/plugins/cccam_user
Restart munin: sudo service munin-node restart. Sit back and relax for 15 minutes, and look at your graphs growing.
By default the webpage of Munin get installed to /var/www/
So to see Munin graph type:
http://you_server_ip/munin
version v0.51
How is it with a Script to catch CCcam.channelinfo unknown CAID:IDENT:SID's ?
And maybe some script which monitors which 'provider' is used mostly...
i mean where you configure something like array( "Sky Germany" "Kabel Deutschland" "HD+" "UnityMedia") and the Script checks how many Users watched it... or maybe CAID based
Download version v0.51
